The goal of this whitepaper series is to create a complete set of printable construction documents (CDs) of a simple 277Y/480V 3Ph 4W commercial office building, starting from a default session of Revit using only out-of-the-box (OOTB) components.

In Phase 1, you’ll learn how to prepare your Revit files for electrical design.

Learning Objectives

  • Prepare the out of the box Revit project template for electrical design
  • Link backgrounds, set up views and create sheets for issuing PDF files
  • Use scope boxes, levels, work planes, title blocks and families

Download the full series!
