The goal of this whitepaper series is to create a complete set of printable construction documents (CDs) of a simple 277Y/480V 3Ph 4W commercial office building, starting from a default session of Revit using only out-of-the-box (OOTB) components.

In Phase 3, you’ll design systems, add details, and print a PDF set of your construction documents.

Learning Objectives

  • Design power and lighting systems, add details and print
  • Add receptacles, data drops, mechanical equipment disconnects and lighting fixtures
  • Finalize sheets for issuing as construction documents (CDs) and print a PDF set of plans
